Hammer-impact jet-vortex mill MH-460
Appointment:
New ideas in turbo-engine technologies.
The hammer-impact rotor-vortex mill MMU-460 is designed for the complete processing of mineral products such as basalt, sand, cement, food materials: grain, husks, various chemical materials: silica gel, glass-filled thermosetting plastic Hytrel @. Grinding of materials to a fraction from 1 to 100 microns occurs by the primary hammer-impact impact on the raw material, as well as due to the created vortices. This complex is a highly efficient solution for the production of various products.
Scopes of this complex:
- Getting fine mineral and building powders;
- Recycling of thermosetting plastics waste;
- Paint and varnish and chemical industry;
- Food production.
The main competitive advantages of our mill:
- Wide range of applications
- Integrated active aerodynamic classifier
- Easy to set up and operate
- Wide possibilities of adding peripheral systems.
Shredded materials
Sand, Chemical products, Basalt, Food products
Particle size of the resulting powder, μm
20-100
Productivity, kg / hour
50-300
Power consumption, kW / hour
35
Overall dimensions (LxWxH), mm
1600х920х1650
Grinding degree, units
50
Size of incoming material, no more, mm
10
